Kniel开关电源EXWUID 20.30 Art no753-000-00
| 聂雪梅 QQ：2853369889 手机：18518172401 电话：010-64714988-172 传真：010-84786709-667 邮件：sales6@handelsen.cn |
 |
 |
拓扑结构：开关模式
输入：100-240 Vac
输出：20.0 V; 30.0安
输出功率：400 W
尺寸：270x150x108毫米
安装：用于壁挂式安装（带配件）
编程：V，I和P可通过RS232，USB，CAN进行数字编程
重量：约3.00公斤
Kniel开关电源EXWUID 20.30 Art no753-000-00,Kniel开关电源
Kniel更多开关电源配件：
Accessories Article-No. Mains connection X1 Connector - PC 4/3-ST-7.62 with cable housing screwable connections 3 pole, 0.2 - 4mm² female 400-116-00 without cable housing 400-130-00 DC-Output connection X2 Connector - IPC 16/3-STF-10.16 male 400-123-00 screwable connection 3 pole, 0.75 - 16mm² Sense lead connection X3 Connector - IC 2.5/2-STF-5.08 male 400-119-00 screwable connection 2 pole, 0.2 - 2.5mm² I/O-Signal connection X4 Connector D-SUB HD 15 pole Stiftleiste 400-106-00 solderable connections until AWG 22 (0.3mm² flex) Loadshare connection X5 Connector - MC 1.5/3-STF-3.81 female 400-120-00 screwable connections 3 pole, 0.14 - 1.5mm² CAN connection X6 Connector RJ45 (2x) 400-104-00 insulation-displacement terminal contacts, AWG 22-26 RS232 connection X7 Connector RJ45 (2x) 400-104-00 insulation-displacement terminal contacts, AWG 22-26
更多产品型号如下
Kniel开关电源EXWUID 20.30 Art no753-000-00,Kniel开关电源
Kniel更多开关电源配件：
Accessories Article-No. Mains connection X1 Connector - PC 4/3-ST-7.62 with cable housing screwable connections 3 pole, 0.2 - 4mm² female 400-116-00 without cable housing 400-130-00 DC-Output connection X2 Connector - IPC 16/3-STF-10.16 male 400-123-00 screwable connection 3 pole, 0.75 - 16mm² Sense lead connection X3 Connector - IC 2.5/2-STF-5.08 male 400-119-00 screwable connection 2 pole, 0.2 - 2.5mm² I/O-Signal connection X4 Connector D-SUB HD 15 pole Stiftleiste 400-106-00 solderable connections until AWG 22 (0.3mm² flex) Loadshare connection X5 Connector - MC 1.5/3-STF-3.81 female 400-120-00 screwable connections 3 pole, 0.14 - 1.5mm² CAN connection X6 Connector RJ45 (2x) 400-104-00 insulation-displacement terminal contacts, AWG 22-26 RS232 connection X7 Connector RJ45 (2x) 400-104-00 insulation-displacement terminal contacts, AWG 22-26
更多产品型号如下
kniel 型号： EXWUID 20.30 Article no： 753-000-00
kniel 型号： EXWUID 20.30/LAN Article no： 753-000-10
kniel 型号： EXWUID 20.30/AN Article no： 753-000-30
kniel 型号： EXWUID 35.17 Article no： 753-001-00
kniel 型号： EXWUID 35.17/LAN Article no： 753-001-10
kniel 型号： EXWUID 35.17/AN Article no： 753-001-30
kniel 型号： EXWUID 52.11 Article no： 753-002-00
kniel 型号： EXWUID 52.11/LAN Article no： 753-002-10
kniel 型号： EXWUID 52.11/AN Article no： 753-002-30
kniel 型号： EXWUID 75.8 Article no： 753-003-00
kniel 型号： EXWUID 75.8/LAN Article no： 753-003-10
kniel 型号： EXWUID 75.8/AN Article no： 753-003-30
kniel 型号： EXWUID 120.6 Article no： 753-004-00
kniel 型号： EXWUID 120.6/LAN Article no： 753-004-10
kniel 型号： EXWUID 120.6/AN Article no： 753-004-30
